Description

This line of fixed displacement bent axis piston pumps were developed with spherical head pistons. This provides extremely high performance and high pressure ratings on
a long life span unit. Flow rates range from 10.5 to 29 GPM. These style pumps-motors are extremely efficient and very compact for easier and inexpensive installations compared to some of the more conventional bearing and bushing designs seen in the market today. Bent Axis pumps-motors will mount directly to virtually any Bezares PTO in our extensive line.

Pump Type 10.4 15.8 20.8 28.9
Code (clockwise) ISO 5042206 5042406 5061006 5042806
SAE 5045406 (z=13) 5045606 (z=13) 5058906 (z=13) 5046006 (z=13)
Code (counterclockwise) ISO 5042306 5042506 5061106 5042906
SAE 5045306 (z=13) 5045506 (z=13) 5059006 (z=15) 5045906 (z=15)
Displacement (cu in/rev) 2.44 3.66 4.88 6.71
Pressure máx. ISO 5076 5076 5076 5076
SAE 4500 4500 4500 4500
Speed r.p.m. max. cont 2000 1700 1500 1400
max. int. 2600 2300 2000 1900
Power Kw cont. 37 45 54 71
máx.int 50 58 66 93
Weight ISO 20.94 22.04 33.06 33.06
SAE 22 23.72 34.39 34.39
